Application
It is usedto test the hot bottom concave measurement of cookware.
Conforms To
DIN EN12983-1:2020 Annex N Figure N.1, BS 7069:1998 Annex A Figure 1,
Cookware Non-stick Surfaces Wear Equipment EN 12983 (Model: SFT S1-2197)
Application
It is usedto test the hot bottom concave measurement of cookware.
Conforms To
DIN EN12983-1:2020 Annex N Figure N.1, BS 7069:1998 Annex A Figure 1,
Specifications
A, Test friction head: Scotch-brite 7447-C
(Test consumablesprepare by the customer, the friction head is replaced every 50 cycles, thenumber of regular tests is 250 cycles)
B, Adjustable range of horizontal: 0-150mm can be set
C, Adjustable range tolerance of horizontal: ±5mm
D, Operating speed adjustment range is 0-80cycles/min (reciprocating fora cycle) can be set
E, Test speed: 6.5±2m/min
F, Test times: 0-9999 times can be set
G, Load block applied on friction block: 15 to 45N±0.2 N
Including 1 weight 15N, 2 weights 1000G, 1weight 500g, 1 weight 535g
H, Touch screen operation, automatic stop after the test times
I, Dimensions: L1000*D500*H500mm
J, Weight: 45Kg
OrderingInformation
SFT S1-2197Cookware Non-stick Surfaces Wear Equipment EN12983--220V 50HZ or 110V 60HZ
