Conforms To
16CFR 1510 / ASTM F 963 clause 4.35 / EN71-1 clause 8.32.1 / ISO 8124-1
Test Fixture for Small Balls (Model:SFT S1-2082)
Application
Smallball test fixture is use to examine a toy up of whether small ball accessoriesmay result in the child swallow, stop breath way and esophagus to cause chokingdanger or not.
Conforms To
16CFR 1510 / ASTM F 963 clause 4.35 / EN71-1 clause 8.32.1 / ISO 8124-1
Specifications
A .Made of aluminum alloy material.
B. Surface hardening process by sandblasting anodic oxidation.
C. Laser engraved permanent unique number, convenient measuring .
D. Optional support frame aided testing.
E. 16CFR 1510 / ASTM F 963 4.35 test standard:
Size: Long*Width*Thick=2.86in(72.6mm)* 2.86in (72.6mm)*0.25in (6m), Hole Dia.1.75in (44.5mm)
EN71 8.16/ ISO8124-1 test standard:
Size: thick 6.4(+0.1-0)mm,Hole Dia.44.5(+0-0.1)mm
OrderingInformation
SFT S1-2082Test Fixture for Small Balls
