Application
Lamp holdertorque tester is applied to measure the torque of lamp cap or holder accordingthe safety requirement.
Lamp holder torque tester (Model:SFT S2-1201)
Lamp holder torque tester is applied to measure the torque of lamp cap or holder accordingthe safety requirement. It is the ideal instrument on lamp cap torque test forthe manufacturer of FL, CFL, filament lamps, HID lamps, LED bulb, energy-savinglamps, incandescent lamps, straight tube fluorescent lamps etc.
Specifications
A. 5-inchLCD touch screen display
B. Candisplay torque values and max. values
C. Max.torque value holding function, upper limit can be set for alarm
D. Fix the lamp head with a fixture,and directly rotate the light source to measure the forward and reverse torqueof the lamp head
E. Torquemeasurement range: 0-10N. m, with a minimum reading of 0.001N. m
F. Measurementaccuracy: 0.5% F.S
G. Equipped with measuring fixturesfor B22, E14, E27, G5/G13 lamp holders (special lamp holder fixtures can becustomized)
H, Dimension: Instrument: D215mm * W310mm * H115mm
Fixture:D220mm * W 300mm * H20mm
K. Weight:15KG (Approx.)
Ordering Information
SFT S2-1201 Lamphold torque tester REV2--220V 50Hz or 115V 60Hz
