Conforms To:
IEC 60061-3, IEC 60238,IEC 60399, IEC 60360, IEC 60432-1
E14 Gauge 7006-27F-1/7006-25-7/7006-30A-1 (Model:SFT G2-5080)
Application:
Safequipment offers a wide range ofgauge to meet the most common standards including those from IEC, EN, UL,GB,DIN,VDE and others. Such standards require the checking of size &definition etc. these gauges are constructed from senior stainless steel andappropriate steel with a hardness and a roughness according to standard require.Each gauge is supplied with a certificate of calibration.
Conforms To:
IEC 60061-3, IEC 60238,IEC 60399, IEC 60360, IEC 60432-1
Specification:
Product Model | Standard | Product Name |
SFT G2-5080 | IEC60061-3,7006-27F-1 | "Go “gauges for E14 caps on finished lamps |
SFT G2-5081 | IEC60061-3,7006-28B-1 | "Not Go “gauges for E14 caps on finished lamps |
SFT G2-5082 | IEC60061-3,7006-54-2 | Gauge for finished lamps fitted with E14 caps for testing contact making |
SFT G2-5083 | IEC60061-3,7006-55-2 | Gauge for finished lamps fitted with E14 caps for testing port. Against acc. Contact Sh. |
SFT G2-5084 | IEC60061-3,7006-27G-1 | "Go"gauges for dimension "S1" of E14 caps on finished lamps |
SFT G2-5085 | IEC60061-3,7006-25-7 | E14"Go"plug gauge for screw threads |
SFT G2-5086 | IEC60061-3,7006-26-4 | E14"Not Go"plug gauge for screw threads of lampholders |
SFT G2-5087 | IEC60061-3,7006-30-2 | E14 plug gauge for lampholders for testing contract making |
SFT G2-5088 | IEC60061-3,7006-31-5 | E14 Gauge for testing contact making and port. Against acc. Contact during insertion |
SFT G2-5089 | IEC60061-3,7006-30A-1 | E14 plug gauge for lampholders with candle shaped shaft for candle lamps for testing contract making |
SFT G2-5090 | IEC60238 FIG 11 | E14 Test Cap for temperature test 14.4 and 19.3 of IEC60238 |
SFT G2-5091 | IEC60399 | E14 External thread "Go"gauges |
SFT G2-5092 | IEC60399 | E14 External thread "Not Go “gauges |
SFT G2-5093 | IEC60238 FIG 13 | E14 test cap A |
SFT G2-5094 | IEC60360 FIG3 | Approximates dimension of test lampholder for E14/20 caps |
SFT G2-5095 | IEC60360 FIG7 | Approximates dimension of test lampholder for E14 / 23*15 caps |
SFT G2-5096 | IEC60360 FIG8 | Approximates dimension of test lampholder for E14 / 25*17caps |
SFT G2-5097 | IEC60432-1 Figure C.2 | E14 Test Holder for torque test on lamps with screw caps |
